PROFIBUS DP Start-up

process data

explanation

identifier

Totalizer value Gas 1

Totalizer value of calibration for
gas 1 in Nl.
Float = 4 bytes

41,83,03 (HEX); PdI

Totalizer value Gas 2

Totalizer value of calibration for
gas 2 in Nl.
Float = 4 bytes

41,83,0d (HEX); PdI

Actual value as float

(4 bytes)
default: 0 –1 00 %
Parameterization of the unit.
(see also “7.4. S-Analog Sensor Object”)

41,83,0E (HEX) PdI
81,83,0E (HEX) PdO

Set-point as float

(4 bytes)
default: 0 – 100 %
Parameterization of the unit.
(see also “7.6. S-Single Stage Controller Object”)

81,83,0E (HEX) PdO

Control output y2

(2 bytes)
Only for MFC control output y2 of the controller, in units
per thousand

Value range 0 … 1000

41,40,10 (HEX); PdI

AddMeasureValue

Additional value as float (4 bytes)
Value as a percentage

This value is only supported by a few MFCs. If the value is
not supported, 0% is returned.

41,83,11 (HEX); PdI

Xp

Additional pressure value (2 bytes)
Value in units per thousand
Value range 0 … 1000

This value is only supported by a few MFCs. If the value is
not supported, 0% is returned.

41,40,12 (HEX); PdI

4.6.

acyclic data

See “7. Acyclic data Transfer with PROFIBUS, deviceNet and CANopen”
