Acyclic Data Transfer with
PROFIBUS, DeviceNet and CANopen
Bürkert mfc family Object
name Description of the input
data attributes attribute address
(class, instance
attribute; data type) Slot, index index, Subindex
Dvn Dpv1 canopen
Status binary
outputs Read only
Bit field for states of binary
outputs (reserved)
See “9.1. description of bit
fields”
min. value 0,
max. value 65535 dec: 110, 1, 10
Hex: 6E, 1, A
WORd
dec: 1, 160
Hex: 1, A0 dec: 12288, 10
Hex: 3000, A
UNSIGNEd16
Status
Hardware Read only
Bit field for the current status
of binary input and output
and the status of LEds
See “9.1. description of bit
fields”
min. value 0,
max. value 65535 dec: 110, 1, 11
Hex: 6E, 1, B
WORd
dec: 1, 161
Hex: 1, A1 dec: 12288, 11
Hex: 3000, B
UNSIGNEd16
Set BinOut
via bus Read Write
Bit field for states of LEds
and binary outputs and for
configuring them via BUS.
The behavior of the device
must be previously con-
figured with the PC software.
MenuViews → DeviceSet-
tings → Assignments of
Inputs and Outputs.
min. value 0,
max. value 65535 dec: 110, 1, 12
Hex: 6E, 1, C
WORd
dec: 1, 162
Hex: 1, A2 dec: 2288, 12
Hex: 3000, C
UNSIGNEd16
Totalizer
gas 1 Read Write
Totalizer value in Nl from the
calibration for gas 1
min. value 0,
max. value 1.00E+39 dec: 110, 1, 13
Hex: 6E, 1, d
REAL
dec: 1, 163
Hex: 1, A3 dec: 12288, 13
Hex: 3000, d
REAL32
Totalizer
gas 2 Read Write
Totalizer value in Nl from the
calibration for gas 2
min. value 0,
max. value 1.00E+39 dec: 110, 1, 14
Hex: 6E, 1, E
REAL
dec: 1, 164
Hex: 1, A4 dec: 2288, 14
Hex: 3000, E
REAL32
Max ramp
time up Read Write
You can set the time delay
(0 – 100 ⇒ 0 – 10 seconds)
that delays a set-point value
jump from 0% to 100%
using a ramp function.
min. value 0, max. value 100 dec: 110, 1, 15
Hex: 6E, 1, F
UINT
dec: 1, 165
Hex: 1, A5 dec: 12288, 15
Hex: 3000, F
UNSIGNEd16
