69

Starting up the Modbus

Response

field name

value

Slave address

0x01

Function

0x84

data field

0x02

Error check

CRC

(high byte)

Error check

CRC

(low byte)

In this example the master addresses a request to slave device 01. The function code 04 stands for “Read Input
Register”. The register address in the device is outside the address validity range and this is why the slave sends
an exceptional reply with the indicated exception code 02 (Illegal data Address).

implemented exceptional replies

code

name

Description

00

Not an error

01

ILLEGAL FUNCTION

Function code is not supported

02

ILLEGAL dATA AddRESS

The data address is not permitted in the device

03

ILLEGAL dATA VALUE

A value included in the request field is incorrect for the
device

04

SLAVE dEVICE FAILURE

Internal device error

Number formats

Data type

Description

length
(bytes)

UINT8

Unsigned integer, 8 bit

1

UINT16

Unsigned integer, 16 bit

2

UINT32

Unsigned integer, 32 bit

4

FLOAT32

Floating-point number in accordance with IEEE-754
The Float32 value is saved in two successive addresses, the first address
includes the most significant word (sign, exponent, and upper part of the man-
tissa), and the second address the least significant word (lower part of the
mantissa)

4

More technical information can be found at www.modbus.org.

english

MFC Family
