CANopen Start-up

process data

explanation

identification

BUS_PdIs

Bit field to select objects for the
process data transfer (Tx)

dec: 16896, 2
Hex: 4200, 2

UNSIGNEd32

Bit 0

Actual value

Bit 1

Set-point value

Bit 2

Active gas

Bit 3

Nominal flow gas 1

Bit 4

Nominal flow gas 2

Bit 5

Status limits

Bit 6

Status errors

Bit 7

Status others

Bit 8

-

Bit 9

-

Bit 10

-

Bit 11

-

Bit 12

Totalizer value gas 1

Bit 13

Totalizer value gas 1

Bit 14

Actual value as Float

Bit 15

Set-point value as Float

Bit 16

-

Bit 17

AddMeasureValue

Bit 18

Xp (not supported yet)

The bit field can be defined by SdO access.

Id

dLC

Byte0

Byte1

Byte2

Byte3

Byte4

Byte5

Byte6

Byte7

600h+Id

8

22

4200H

02H

Bit field
