14

Serial Communication

command number
command name

0x03
readcurrentandfourDynamicvariables

request
Command

0x03

Byte count

0

data

-

response
Command

0x03

Byte count

26

Status

2 bytes, device status

data

24 bytes
0 – 3

current (mA) (float)

1)

4

PV units code

5 – 8

primary variable (float)

1)

9

SV units code

10 – 13

secondary variable (float)

1)

14

TV units code

15 – 18

third variable (float)

1)

19

FV units code

20 – 23

fourth variable (float)

1)

Description

HART-Universal Command 3.

New variable assignment as of firmware version A.00.28.09:

current Actual flow scaled to 4 – 20 mA

PV Unit %
PV

Actual flow X (±)

SV Unit %
SV

Set-point value flow W

TV Unit %
TV

Positioning set-point value y 2 (valve duty cycle)

FV Unit sec
FV

device sampling time,

since power-on or SyncTA command

1)

First byte transferred: MSB

english

MFC Family
