34

DeviceNet Start-up

5.

DeviCeneT STarT-up

5.1.

Terms

Devicenet

deviceNet is a field bus system based on the CAN protocol (Controller Area Network). It enables actuators and
sensors (slaves) to be networked with higher-level controllers (master).

The deviceNet profile "Mass Flow Controller device" is supported with strict compliance to deviceNet
specifications.

With deviceNet it is necessary to differentiate between cyclical or event-driven high-priority process messages
(I/O messages) and acyclical low-priority management messages (explicit messages).

protocol sequence

The protocol process conforms to the deviceNet specification Release 2.0.

technical Data

eDS file

BUER8626.EdS

icons

BUER8626.ICO

Baudrate

125, 250, 500 kBit/s
Factory setting 125 kBit/s

address

0 – 63
Factory setting 63

process data

5 static input assemblies
4 static output assemblies

english

MFC Family
