9.
anhang
9.1.
Beschreibung der Bitfelder
9.1.1.
Bitfeld liMiTS
Bitfeld limitS
Bit 0
x > Limit1_x
Bit 1
x < Limit1_x
Bit 2
x > Limit2_x
Bit 3
x < Limit2_x
Bit 4
w > Limit1_w
Bit 5
w < Limit1_w
Bit 6
w > Limit2_w
Bit 7
w < Limit2_w
Bit 8
y2 > Limit1_y2
Bit 9
y2 < Limit1_y2
Bit 10
y2 > Limit2_y2
Bit 11
y2 < Limit2_y2
Bit 12
Totalizer [aktives Gas] > Limit1_Totalizer
Bit 13
Totalizer [aktives Gas] < Limit1_Totalizer
Bit 14
Totalizer [aktives Gas] > Limit2_Totalizer
Bit 15
Totalizer [aktives Gas] < Limit2_Totalizer
9.1.2.
Bitfeld errOrS
Bitfeld errOrS
Bit 0
Current out of Range / Strom außerhalb des Toleranzbereiches
Bit 1
Error >Power LEd< / Fehler >Power LEd<
Bit 2
Error >Communication LEd< / Fehler >Communication LEd<
Bit 3
Error >Limit LEd< / Fehler >Limit LEd<
Bit 4
Error >Error LEd< / Fehler >Error LEd<
Bit 5
Error BinOut 1 / Fehler BinOut 1
Bit 6
Error BinOut 2 / Fehler BinOut 2
Bit 7
Error Internal Supply Voltage / Fehler Interne Spannungsversorgung
Bit 8
Error Sensor Supply Voltage / Fehler Spannungsversorgung-Sensor
Bit 9
Error data Storage / Fehler datenspeicher
Bit 10
RESERVEd / reserviert
Bit 11
RESERVEd / reserviert
Bit 12
Error Sensorfault / Sensorfehler
Bit 13
Error after autotune / Fehler nach Autotune
Bit 14
Error BusModul MFI / Fehler Bus-Modul MFI
Bit 15
Stack Overflow / Stack Überlauf
