75

Starting up the Modbus

register
address in
mfc

number of
register

name / Description

r/w

type

0017

1

Stopbit
defines the number of stop bits of the Modbus
communication.

Value Number of Stop bit
1

1 Stop bit

2

2 Stop bits

Attention please:

• A changed value will be active after a device reset..

R/W

UINT16

0018

1

Timeout detection Time (In Second)

Timeout detection is implemented in the MFC device. The
detection time can be specified by this register. The default
value is 60 (seconds)
If the time between two pollings is longer than the specified
time, a timeout will be detected. After timeout detection the
device will be set into a safety mode. In this case the set
point will be set to 0 and the valve will be closed. The timeout
detection can be disabled by a value of 0.

Range: 0 – 60

R/W

UINT16

0019

1

Modbus device Address

Address by which the Modbus master communicates with the
device

1 – 32

R/W

UINT16

0020…0021 2

Flow Full Scale

Unit see Holding Register → “Unit Flow Value”

R

FLOAT32

0022…0025 4

Unit Flow Value

Unit of the flow value

R

UINT16

1)

ASCII_2

0026…0029 4

Operating Medium

Operating medium

R

UINT16

1)

ASCII_2

0030…0031 2

device Serial Number
Bürkert serial number of the device

min. value 0, max. value 4294967295

R

UINT32

0032

1

Version Number Hardware

see description “Versions of the hardware”, page 76

R

UINT16

0033

1

Version Number Software

see description “Versions of the software”, page 76

R

UINT16

0034

1

Active Gas
Active Gas / calibration of this gas is used for control.

Value Gas
0

Gas 1

1

Gas 2

R/W

UINT16

english

MFC Family
