54

Acyclic Data Transfer with
PROFIBUS, DeviceNet and CANopen

S-analog Sensor Object

name

Description of the input data
attributes

attribute address
(class, instanceat-
tribute; data type)

Slot, index

index, Subindex

Dvn

Dpv1

canopen

Flow Full
Scale

Read only

depends on the settings under
data type and data units.

dec: 49, 1, 10
Hex: 31, 1, A

INT

Or

REAL

dec: 1, 10
Hex: 1, A

dec: 8448, 7
Hex: 2100, 7

INTEGER16

Or

dec: 8448, 8
Hex: 2100, 8

REAL32

7.5.

S-analog actuator Object

S-analog actuator Object
name

Description of the input data
attributes

attribute address
(class, instance
attribute; data
type)

Slot, index

index, Subindex

Dvn

Dpv1

Dpv1

data Type

Read Write
describes the data format of the
"value"

Hex
0xC3 INT
0xCA REAL

dec: 50, 1, 3
Hex: 32, 1, 3

USiNT

dec: 1, 53
Hex: 1, 35

dec: 8704, 1
Hex: 2200, 1

UNSIGNEd8

data Units

Read Write
min. value 2048
max. value 4103

Possible units are:

"% "

"Units per thousand"

0x800 "Units per thousand"
0x1007 "% "

dec: 50, 1, 4
Hex: 32, 1, 4

UINT

dec: 1, 54
Hex: 1, 36

dec: 8704, 2
Hex: 2200, 2

UNSIGNEd16

english

MFC Family
