Burkert Type 8693 User Manual
Page 109

109
Start-up and operation of the
position controller Type 8692
Position
set-point
value
Control
difference
Xd1
Position
actual value
to the controller
Xd1‘
Dead band
Xd1
Xd1‘
Figure 63:
Graph X.CONTROL
kx xxx
parameters for the position controller
KXopn
Amplification factor of the position controller (for closing the valve)
KXcls
Amplification factor of the position controller (for opening the valve)
english
Type 8692, 8693
