Chapter 4 Wizard Setup
ZyWALL USG 100/200 Series User’s Guide
77
The following table describes the labels in this screen.
4.3 Step 1 Internet Access
Encapsulation: Choose the Ethernet option when the WAN port is used as a regular
Ethernet. Otherwise, choose PPPoE or PPTP for a dial-up connection according to the
information from your ISP.
WAN Interface: This is the interface you are configuring for Internet access.
Zone: This is the security zone to which this interface and Internet connection belong.
IP Address Assignment: Select Auto If your ISP did not assign you a fixed IP address.
Select Static If the ISP assigned a fixed IP address.
4.3.1 Ethernet: Auto IP Address Assignment
If you select Auto as the IP Address Assignment in the previous screen, the following screen
displays. Click Next to apply the configuration settings.
Table 7 Internet Access: Step 1
LABEL DESCRIPTION
ISP Parameters
Encapsulation Choose the Ethernet option when the WAN port is used as a regular Ethernet.
Otherwise, choose PPPoE or PPTP for a dial-up connection according to the
information from your ISP.
WAN IP Address
Assignments
WAN Interface This is the interface you are configuring for Internet access.
Zone This is the security zone to which this interface and Internet connection belong.
IP Address
Assignment Select Auto If your ISP did not assign you a fixed IP address.
Select Static If the ISP assigned a fixed IP address.
Next Click Next to continue.
