Chapter 20 IPSec VPN
ZyWALL USG 100/200 Series User’s Guide
371
20.5 The SA Monitor Screen
You can use the SA Monitor screen to display and to manage active IPSec SAs. To access this
screen, click VPN > IPSec VPN > SA Monitor. The following screen appears.
Member This field displays the name of each member in the concentrator.
Note: You must disable policy enforcement in each member. See
Section 20.2.1 on page 355 .
Click the Popup icon to change this member in the group. The following screen
appears.
IPSec VPN connection policies that do not belong to a VPN concentrator appear
on the left. Select any VPN connection policies that you want to add to the VPN
concentrator and click the right arrow button to add them.
The VPN concentrator’s member VPN connections appear on the right. Select
any VPN connections that you want to remove from the VPN concentrator, and
click the left arrow button to remove them.
Figure 259 Network > IPSec VPN > Concentrator > Edit > Member
Add icon This column provides icons to add members to and remove members from the
concentrator.
Click an Add icon at the top of the column to add a new member at the beginning
of the list, or click the Add icon next to an existing member to add a new member
after the existing one. The Member List screen appears. See the member
Popup description for more details.
To remove a member from the concentrator, click on the Remove icon next to the
member. The web configurator confirms that you want to remove the member.
OK Click OK to save your changes in the ZyWALL.
Cancel Click Cancel to exit this screen without saving.
Table 121 VPN > IPSec VPN > Concentrator > Edit (continued)
LABEL DESCRIPTION
