ZyXEL Communications 200 Series - Manual (Page 223)

Chapter 10 Interface
ZyWALL USG 100/200 Series User’s Guide
223
Figure 161 Network > Interface > PPP > Edit > Configuration
Each field is explained in the following table.
Table 60 Network > Interface > PPP > Edit > Configuration
LABEL DESCRIPTION
General Settings
Enable Interface Select this to enable this interface. Clear this to disable this interface.
Interface Properties
Interface Name This field is read-only and displays the name of the PPP interface. The format is
the name of the physical port followed by “ppp”. For example, “wan1_pppoe”.
Zone For the OPT port, select to which zone this PPP interface belongs. For PPP
interfaces on a WAN interface, this field is read-only.
Base Interface This field is read-only and displays the name of the interface upon which this
PPP interface is built.
