Chapter 10 Interface
ZyWALL USG 100/200 Series User’s Guide
217
Figure 155 Interface Wizard: WAN Interface Zone and IP Address Setup
The following table describes the labels in this screen.
10.5.5 Interface Wizard: WAN ISP Connection Settings
Use this screen to configure the ISP and WAN interface settings.
Figure 156 Interface Wizard: WAN ISP Connection Settings (PPTP, Static IP Shown)
Table 55 Interface Wizard: WAN Interface Zone and IP Address Setup
LABEL DESCRIPTION
WAN Interface This is the interface you are configuring for Internet access.
Zone Select to which zone this interface and Internet connection will belong to. You
configure security policies by zone.
IP Address
Assignment Select Auto If your ISP did not assign you a fixed IP address.
Select Static If the ISP assigned a fixed IP address.
Back Click Back to return to the previous screen.
Next Click Next to continue to Section 10.5.5 on page 217
