Chapter 46 Reports
ZyWALL USG 100/200 Series User’s Guide
729
Flush Data Click this button to discard all of the screen’s statistics and update the report
display.
These fields are available when the Traffic Type is Host IP Address/User.
# This field is the rank of each record. The IP addresses and users are sorted by the
amount of traffic.
IP Address/User This field displays the IP address or user in this record. The maximum number of IP
addresses or users in this report is indicated in
Table 259 on page 730 .
Direction This field indicates whether the IP address or user is sending or receiving traffic.
Ingress- traffic is coming from the IP address or user to the ZyWALL.
Egress - traffic is going from the ZyWALL to the IP address or user.
Amount This field displays how much traffic was sent or received from the indicated IP
address or user. If the Direction is Ingress, a red bar is displayed; if the Direction
is Egress, a blue bar is displayed. The unit of measure is bytes, Kbytes, Mbytes or
Gbytes, depending on the amount of traffic for the particular IP address or user.
The count starts over at zero if the number of bytes passes the byte count limit. See
Table 259 on page 730 .
These fields are available when the Traffic Type is Service/Port.
# This field is the rank of each record. The protocols and service ports are sorted by
the amount of traffic.
Service/Port This field displays the service and port in this record. The maximum number of
services and service ports in this report is indicated in
Table 259 on page 730 .
Protocol This field indicates what protocol the service was using.
Direction This field indicates whether the indicated protocol or service port is sending or
receiving traffic.
Incoming - traffic is coming into the router through the interface
Outgoing - traffic is going out from the router through the interface
Amount This field displays how much traffic was sent or received from the indicated service
/ port. If the Direction is Ingress, a red bar is displayed; if the Direction is Egress,
a blue bar is displayed. The unit of measure is bytes, Kbytes, Mbytes, Gbytes, or
Tbytes, depending on the amount of traffic for the particular protocol or service port.
The count starts over at zero if the number of bytes passes the byte count limit. See
Table 259 on page 730 .
These fields are available when the Traffic Type is Web Site Hits.
# This field is the rank of each record. The domain names are sorted by the number
of hits.
Web Site This field displays the domain names most often visited. The ZyWALL counts each
page viewed on a Web site as another hit. The maximum number of domain names
in this report is indicated in
Table 259 on page 730 .
Hits This field displays how many hits the Web site received. The ZyWALL counts hits
by counting HTTP GET packets. Many Web sites have HTTP GET references to
other Web sites, and the ZyWALL counts these as hits too. The count starts over at
zero if the number of hits passes the hit count limit. See
Table 259 on page 730 .
Table 258 Maintenance > Report > Traffic Statistics (continued)
LABEL DESCRIPTION
