Chapter 7 Status
ZyWALL USG 100/200 Series User’s Guide
181
The following table describes the labels in this screen.
7.2.7 The Port Statistics Graph Screen
Use this screen to look at a line graph of packet statistics for each physical port. To access this
screen, click Port Statistics in the Status screen and then the Switch to Graphic View
Button.
Table 38 Status > Port Statistics
LABEL DESCRIPTION
Switch to
Graphic View Click this to display the port statistics as a line graph.
Port This field displays the physical port number.
Status This field displays the current status of the physical port.
Down - The physical port is not connected.
Speed / Duplex - The physical port is connected. This field displays the port speed
and duplex setting (Full or Half).
TxPkts This field displays the number of packets transmitted from the ZyWALL on the
physical port since it was last connected.
RxPkts This field displays the number of packets received by the ZyWALL on the physical
port since it was last connected.
Collisions This field displays the number of collisions on the physical port since it was last
connected.
Tx B/s This field displays the transmission speed, in bytes per second, on the physical port
in the one-second interval before the screen updated.
Rx B/s This field displays the reception speed, in bytes per second, on the physical port in
the one-second interval before the screen updated.
Up Time This field displays how long the physical port has been connected.
System Up Time This field displays how long the ZyWALL has been running since it last restarted or
was turned on.
Poll Interval Enter how often you want this window to be updated automatically, and click Set
Interval.
Set Interval Click this to set the Poll Interval the screen uses.
Stop Click this to stop the window from updating automatically. You can start it again by
setting the Poll Interval and clicking Set Interval.
