Locator Tool Properties
The Locator finds and locates objects based on the geometry of their contours. Scale factor, orientation,
and position are provided for each located instance. Models are built using the integrated Model Editor.
Property Name
V+/MicroV+
Keyword V+/-
MicroV+ ID
Access Type
CalibratedUnitsEnabled VPARAMETER 103 R - O Boolean
ConformityTolerance VPARAMETER 556 R / W Double
ConformityToleranceRangeEnabled VPARAMETER 553 R / W Boolean
ContrastPolarity VPARAMETER 522 R / W Long
ContrastThreshold VPARAMETER 303 R / W Long
ContrastThresholdMode VPARAMETER 302 R / W Long
CoordinateSystem VPARAMETER 1000 R / W Long
DefaultConformityTolerance VPARAMETER 552 R - O Double
DetailLevel VPARAMETER 301 R / W Long
ElapsedTime VRESULT 1001 R - O Double
FrameCount VRESULT 2410 R - O Long
FrameRotation VRESULT 2402 R - O Double
FrameTranslationX VRESULT 2400 R - O Double
FrameTranslationY VRESULT 2401 R - O Double
InstanceClearQuality VRESULT 1319 R - O Double
InstanceCount VRESULT 1310 R - O Long
InstanceFitQuality VRESULT 1317 R - O Double
InstanceIntrinsicBoundingBox VRESULT 1330 R - O Double
InstanceLocation VLOCATION 1311 R - O Location
InstanceLocationGripperOffsetMaximum VLOCATION 1499 R - O Location
InstanceLocationGripperOffsetMinimum VLOCATION 1400 R - O Location
InstanceMatchQuality VRESULT 1318 R - O Double
InstanceModel VRESULT 1312 R - O Long
InstanceOrdering VPARAMETER 530 R / W Long
InstanceOrderingReferenceX VPARAMETER 531 R / W Double
InstanceOrderingReferenceY VPARAMETER 532 R / W Double
