FitQuality
VRESULT
1803
Normalized average error between the calculated arc or line entity and the actual edges matched to the
found entity. Fit quality ranges from 0 to 1, with 1 being the best quality. A value of 1 means that the
average error is 0. Conversely, a value of 0 means that the average matched error is equal to Conformity
Tolerance. Read only.
Syntax
MicroV+
value = VRESULT (sequence_id, tool_id, instance_id, 1803, index_id, frame_id )
V+
value = VRESULT ($ip, sequence_id, tool_id, instance_id, 1803, index_id, frame_id )
Type
Double
Range
Minimum: 0.0
Maximum: 1.0
Parameters
sequence_id Index of the vision sequence. The first sequence is 1.
tool_id Index of the tool in the vision sequence. The first tool is 1.
instance_id Index of the instance for which you want the result.
ID 1803: the value used to reference this property.
index_id N/A
frame_id Index of frame that contains the specified instance.
FitQuality
