C5/K1/K3 Integrated Satellite Terminal System

Remote Control Operation

Rev. 0

B–37

Character 'p': Interface backward alarm status character 1.

Bit 6 = 1 always.
Bit 5 = reserved.
Bit 4 = reserved.
Bit 3 = reserved.
Bit 2 = reserved.
Bit 1 = reserved.
Bit 0 = reserved.

Character 'q': Interface backward alarm status character 2.

Bit 6 = 1 always.
Bit 5 = reserved.
Bit 4 = reserved.
Bit 3 = reserved.
Bit 2 = reserved.
Bit 1 = reserved.
Bit 0 = reserved.

Character 'r': Interface Reed-Solomon Unavailable
Seconds.

Bit 6 = 1 always.
Bit 5 = not used.
Bit 4 = not used.
Bit 3 through Bit 0 = Binary representation (0 to 10) of
the number of Reed-Solomon Unavailable Seconds
stored faults.

Character 's': Outdoor Unit fault status character 1.

Bit 6 = 1 always.
Bit 5 = Module.
Bit 4 = reserved.
Bit 3 = reserved.
Bit 2 = reserved.
Bit 1 = reserved.
Bit 0 = reserved.
