Options C5/K1/K3 Integrated Satellite Terminal System
A–14 Rev. 0
The following table lists examples.
If DR = 8.000K Baud rate can be 150 or lower
If DR = 16.000K Baud rate can be 300 or lower
If DR = 32.000K Baud rate can be 600 or lower
If DR = 64.000K Baud rate can be 1200 or lower
If DR = 128.000K Baud rate can be 2400 or lower
If DR = 256.000K Baud rate can be 4800 or lower
If DR = 512.000K Baud rate can be 9600 or lower
If DR = 1024.000K Baud rate can be 19200 or lower
If DR = 2048.000K Baud rate can be 38400 or lower
A.2.1.4 Front Panel Operation
For information on the additional front panel operations that are specific to the ASYNC
interface, refer to Chapter 4. The following menus are affected:
! Configuration Interface
! Configuration Local AUPC
! Remote AUPC Configuration
! Remote AUPC Monitor
! Utility Interface
A.2.1.5 ASYNC Remote Operation
Remote modems can be controlled over the ASYNC channel from the local (or “hub”)
modem. Refer to Table A-2 for a list of combinations:
Table A-2. ASYNC Remote Operation
Configuration # Local Modem To Remote Modem Table #
1 EIA-232 EIA-232 Table A-3
2 EIA-232 EIA-485 (2-wire) Table A-4
3 EIA-485 (2-wire) EIA-232 Table A-5
For each of the above combinations, front panel control settings and pinouts for local and
remote cables are listed in the following sections.
