Operation

C5/K1/K3 Integrated Satellite Terminal System

4–22

Rev. 0

ASYNC RX BAUD

Programs the ASYNC overhead RX baud rate for 110 to 38400 bit/s.

Upon entry, the status of the ASYNC RX baud rate is displayed.
Press [

$] or [%] to select on of the following baud rates (bit/s): 110,

150, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400.

Press [ENTER] to execute the change.

Note: Only available for the ASYNC option.

ASYNC TX LENGTH

Programs the ASYNC overhead TX word length for 5, 6, 7, or 8 bits.

Upon entry, the status of the ASYNC TX word length is displayed.
Press [

$] or [%] to select the selection. Press [ENTER] to execute the

change.

Note: Only available for the ASYNC option.

ASYNC RX LENGTH

Programs the ASYNC overhead RX word length for 5, 6, 7, or 8 bits.

Upon entry, the status of the ASYNC RX word length is displayed.
Press [

$] or [%] to select the selection. Press [ENTER] to execute the

change.

Note: Only available for the ASYNC option.

ASYNC TX STOP

Programs the ASYNC overhead TX stop bits for 1 or 2.

Upon entry, the status of the ASYNC TX stop bits is displayed. Press
[

$] or [%] to select the selection. Press [ENTER] to execute the

change.

Note: Only available for the ASYNC option.

ASYNC RX STOP

Programs the ASYNC overhead RX stop bits for 1 or 2.

Upon entry, the status of the ASYNC RX stop bits is displayed. Press
[

$] or [%] to select the selection. Press [ENTER] to execute the

change.

Note: Only available for the ASYNC option.

ASYNC TX PARITY

Programs the ASYNC overhead TX parity for EVEN, ODD, or
NONE.

Upon entry, the status of the ASYNC TX parity is displayed. Press
[

$] or [%] to select the selection. Press [ENTER] to execute the

change.

Note: Only available for the ASYNC option.

ASYNC RX PARITY

Programs the ASYNC overhead RX parity for EVEN, ODD, or
NONE.

Upon entry, the status of the ASYNC RX parity is displayed. Press
[

$] or [%] to select the selection. Press [ENTER] to execute the

change.

Note: Only available for the ASYNC option.
