C5/K1/K3 Integrated Satellite Terminal System Operation
Rev. 0 4–31
4.1.3.7 Monitor
Refer to Figure 4-10.
When the Monitor level is entered press [
"] or [#] to select the desired monitor
function. Each monitor function is displayed in real time as long as it is selected.
RAW BER Displays the current BER or “No Data” (if carrier is not locked).
Range: < m.m E-e to > m.m E-e.
Note: Low limit is based on performance. High limit is based on
data/code rate.
CORRECTED BER Displays the current corrected BER or “No Data” (if carrier is not
locked).
Range: 1.0 E-3 to 1.0 E-12.
EB/N0 Displays the current Eb/N0 or “No Data” (if carrier is not locked).
Range: 2.0 to 16.0 dB.
RECEIVE SIGNAL Displays the current receive signal level.
Range: -25.0 to -95.0 dBm for symbol rates
' 190 ks/s.
-15.0 to -85.0 dBm for symbol rates > 190 ks/s.
SWEEP FREQUENCY Displays the current offset frequency or “No Data” (if carrier is not
locked).
Range: -35,000 to +35,000 Hz.
BUFFER FILL Displays the current plesiochronous buffer fill status percent.
Range: 1 to 99%.
P.S. TEMPERATURE Displays the current P.S. temperature in degrees Celsius.
Range: -55
( to +125(C (-67( to +257(F).
FRAME ERRORS Displays current frame errors or data if carrier/2047 is not locked.
Note: Available with Overhead card only.
L-BAND RX FREQUENCY Displays the frequency being received at the RX input of the IDU.
Range: 950 to 1450 MHz (in 100 Hz steps)
