5Ć39 Using the System Configurator
If any UDC modules exist in the destination rack, you will be
prompted for which operating systems to erase (AutoMax or UDC).
The warning Erase UDC OS before AutoMax OS when erasing all
Processors" will be displayed with the prompt. You can choose to
erase either the OSs on all Processors in the rack or the OS for a
UDC module in the slot you designate. If you want to delete the
operating systems for all AutoMax Processors and UDC modules in
the rack, you must delete the UDC OSs first.
5.4.5 Repairing Databases
In some cases, the Programming Executive will display an error
message which states that the database index files do not match the
database files. This should not occur during normal operation.
Usually, this error occurs if the database files have been changed
without using the Programming Executive or if a Programming
Executive operation was interrupted by turning off the personal
computer. This message will instruct you to use the Repair System
Databases or Repair Rack Databases command. These
commands will reĆindex all index files for the selected system or
selected rack, respectively.
5.5 Setup Menu
The Setup menu is used to modify the Windows configuration and to
set up AutoMax Executive V3.x. You should set up both AutoMax
Executive V3.x and Windows when you install the software.
5.5.1 Modifying the Windows Configuration
Select Windows from the Setup menu to make changes to the
Windows configuration. The Windows Control Panel will be
displayed. See the Microsoft Windows User's Guide for instructions
on using the Windows Control Panel.
Note that in order to print PC tasks (ladder diagrams) and cross
reference files properly, your printer must be capable of printing in
compressed mode (132 columns). You can choose to print in either
landscape or portrait orientation. All printed output will be generated
according to the parameters defined in the Printers setup in
Windows.
5.5.2 Modifying the AutoMax Executive Configuration
with Setup
Select AutoMax from the Setup menu to make changes to the
AutoMax Executive configuration. The Setup dialog box (see
figure 5.16) will display default entries. You can make changes to any
the following fields:
Library Drive Ć Enter the letter of the drive containing the
library you want to work with.
Library Directory Ć The library is the base directory which
will contain the systems you want to work with. The default
library is AMXLIB. You can accept the default or enter the
name of your library directory.
