11Ć1 AutoMax On Line Menu
11.0 AutoMax ON LINE MENU
The ON LINE! command in the System Configurator and the Task
Manager applications allows you to select the ON LINE menu shown
in figure 11.1. Options on this menu are used to load, run, stop,
monitor, and modify application tasks in the rack and to connect to
other racks on the network(s). In addition, this menu provides access
to the error log kept for each AutoMax Processor or UDC module
running tasks.
Before attempting to use any of the options in the ON LINE menu,
you must load the operating system onto the Processor modules and
UDC modules in the rack if you have not already done so. Refer to
5.4.3 for directions on loading the operating system.
Transfer
Config NORMAL Keysw Program Access Task Auto Run DISABLED
Slot Task ăăăă Type ăăPri R C M A Status Slot Task ăăăăăăăăăType Pri R C M A Status
"1 ATASK Bas 7 U Stop
6 UDC1TSK Blk A Stop
ON LINE direct AutoMax C: \AMXLIB3\SYSDNR\RACK1
Run F3ăExit EnterăSelect Connect Delete Info/Log
F1ăHelp Stop Monitor Error Clear
Figure 11.1 Ć ON LINE Menu
When you select ON LINE you will be prompted to connect the cable
to the leftmost Processor in the rack and then type Enter" or
if the cable is not already connected. If you have already connected
the cable, simply enter a to go online. If you have not
connected the cable, refer to the directions in 3.4. Once you are
online, you will see the menu shown in figure 11.1.
When you first go into the ON LINE menu, the fields in the status line
displayed on the screen directly beneath the horizontal line will be
empty if there are no tasks loaded on the rack at this time. A sample
display when there is one task running in the rack is described in
11.3 and shown in figure 11.2.
Use F3 to exit the ON LINE menu and return to the System
Configurator or Task Manager application.
