Other Methods of Setting UP Meter Ports
PMI meter ports can be set up during DPS parameter entry on on the
Monitor Setup UDC/PMI menu. UDC meter ports can be set up via
registers 1001-1017 in a UDC application task or on the Monitor
Setup UDC/PMI menu. The setup information may be retained after a
Stop All or power cycle depending on the method used. See the
table below.
Table 18.1 - Meter Port Setup Retention
UDC Setup
via Monitor
Menu
UDC Setup via
Application
Task (Reg.
1001Ć 1017)
PMI Setup
during
Parameter
Entry
PMI Setup
via Monitor
Menu
Retained after
Stop All?
Yes Yes* Yes No**
Retained after
power cycle
No Yes* Yes No**
ă*Original task setup is retained.
**If the PMI meter ports are set up using the parameter screens and then later set
up again using the Monitor menu, the setup in the parameter screens will still
be retained.
ON LINE direct Udc Slot 06 AUTOMAX C: \AMXLIB3\SYSDNYR\RACK1
Monitor Setup UDC/PMI
EscăExit UDC AăPMI BăPMI
F1 Help
Loc Port Task VarName/RegNum
UDC ă1 S5ASPD CML_WCO%
UDC ă2 S5ASPD RES_GAN
UDC ă3 00201
UDC ă4 00690
Loc
Port Par Num Description Val @Ć10V Val @+10V
PMIĆA 1 ă4 ArmVolt.(Volts E0) -32767 32700
PMIĆA 2 16 ACRMSLineV(Volts E0) 0 10
PMIĆA 3 ă3 ArmCurFdBk(Amps E1) 0 32700
PMIĆA 4
PMIĆB 1
PMIĆB 2
PMIĆB 3
PMIĆB 4
Bit Val @Ć10V Val@+10V
0 32767
0 255
3 -100 100
Figure 18.9 Ć UDC Setup Screen
You can display and output to the selected port any variable mapped
to a UDC register (common) or any local variable. The task name is
required for local variables.
