5Ć25
Using the System Configurator
D Task documentation file
D Task source code
D Task cross reference file
If you deĆselect (uncheck) Rack Print, the Custom Print options will
be enabled.
Select Rack Documentation to print out the rack documentation file.
Select Rack Cross Reference to print the cross reference file for the
selected rack(s).
Select All Rack Parameters to print the drive parameters for all the
UDC modules in the rack.
Select Parameters for Module in Slot: to print the drive parameters
for a particular UDC module in the rack. You must enter the slot
number of the UDC module.
Note that the two rack parameters options are mutually exclusive.
Select Use Existing Cross Reference Files if you know that the
cross reference files are current. Selecting this option will save time
since new files will not be generated before printing. If cross
reference files do not already exist, they will be generated and
printed. Note that cross reference files generated by the print routine
will be deleted after printing.
Select Generate Log to create a log file that will list any errors that
may occur during the print job. Each rack will have a separate log
file. The log file will exist under the rack directory and will be named
_PRINT.LOG. If there are no errors, the log file will simply list the files
that were printed.
5.3.8
Transferring a Rack
You can copy all the files for one or more selected AutoMax Executive
racks to diskettes (or another hard drive, or another library on the
same drive), or copy all the files for an AutoMax Executive rack from
diskettes (or a hard drive) into the current AutoMax library (see
section 5.1.7 for additional information). If you are transferring to
diskettes, you will need at least one diskette for each rack. You will be
prompted for additional diskettes, if needed. Diskettes can be
formatted as needed or, to save time, you can use blank
preĆformatted diskettes. Use the following procedure to transfer
racks. Figure 5.13 illustrates the Transfer Rack dialog box.
Step 1.
Select the rack(s) to be transferred from the rack list.
Step 2.
Select Transfer from the Rack menu. The Transfer dialog
box will be displayed with the current drive and library (as
designated in AutoMax Setup) listed in a box on the top
left.
Step 3.
Enter information for the following fields. Some fields may
contain default entries. If you do not change these fields,
the default will be used.
Direction arrows Ć Transfer the rack To (left arrow) or From
(right arrow) the current library. Select the appropriate
option button.
Drive Ć Enter the source drive or the destination drive. If A
or B is entered, the Executive software assumes the drive
