Using MPS Explorer Chapter 5
Data Visualization/Trending
MPS Data Visualization and Trending allow the user to configure the display
with specific metering data as well as Relay Word Bits that are then mapped to
graphs, gauges and bit indicators so that parameters can be monitored visually.
Each indicator auto scales to provide the best fit for the data for easy viewing. The
MPS Trending window is independent of the main application window, which
allows the user to switch back and forth without closing a window. The user can
display:
• Current (Average Magnitude, Average Line, Angle, Imbalance)
• Voltage (Angle, Imbalance, Magnitude)
• Frequency
• Ground Fault Current (Core Balance, Residual)
• Motor Load
• Power (Apparent, Reactive, Real, Power Factor)
• Temperature (Ambient, Bearing Rise, Winding, Thermal Capacity Used)
• Input states
• Auxiliary relay states
• Trip conditions
The parameters can be mapped to a specific bit, gauge or graph assignment.
The Data Acquisition Settings dialog window has tabs along the top that can
be selected and configured. To assign a parameter a specific location and display
form, select a parameter from the Data Available column (left column) as well
as a unassigned location from the Assignment column (right column). When
