Rockwell Automation Publication 825-UM004D-EN-P - April 2012 247
DeviceNet Information Chapter E
Standard Input (Produced)
Assemblies
Instance 50 is the required input (produced) assembly defined in the DeviceNet
Motor Overload Profile.
Instance 51 is the required input (produced) assembly defined in the DeviceNet
Motor Starter Profile.
Instance 101 is the 825 Average Current Overload Input (produced) assembly.
Instance 102 is the 825 Phase Current Input (produced) assembly.
Instance 50 ODVA Overload
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Fault
Instance 51 ODVA Starter
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Warning Fault
Instance 101 825 Average Current Overload
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Warning Tripped
1 Reserved
2 Average 3 Phase Current (low)
3 Average 3 Phase Current (high)
Instance 102 825 Phase Current
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Warning Tripped
1 Reserved
2 Current Phase L1 (low)
3 Current Phase L1 (high)
4 Current Phase L2 (low)
5 Current Phase L2 (high)
6 Current Phase L3 (low)
7 Current Phase L3 (high)
