196 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter B Parameter List
Status
(cont.)
7 MODULE STATUS 0 = Explicit Conn. 0 — — Get/Set
1 = I/O Conn. 0
2 = Explicit Fault 0
3 = I/O Fault 0
4 = I/O Idle 0
5 = Reserved 0
6 = Reserved 0
7 = Reserved 0
8 = Fault 0
9 = Warning 0
10 = Starting 0
11 = Running 0
12 = Stopped 0
DeviceNet
8 AUTOBAUD ENABLE 0 = Disabled
1 = Enabled
0 — — Get/Set
9 CONSUMED IO ASSY 0 188 150 — — Get/Set
10 PRODUCED IO ASSY 0 189 103 — — Get/Set
11 PROD ASSY WORD 0 0 447 1 — — Get/Set
12 PROD ASSY WORD 1 0 447 3 — — Get/Set
13 PROD ASSY WORD 2 0 447 4 — — Get/Set
14 PROD ASSY WORD 3 0 447 5 — — Get/Set
15 PROD ASSY WORD 4 0 447 6 — — Get/Set
16 PROD ASSY WORD 5 0 447 7 — — Get/Set
17 PROD ASSY WORD 6 0 447 0 — — Get/Set
18 PROD ASSY WORD 7 0 447 0 — — Get/Set
19 CONSUMED IO SIZE 0 6 2 — — Get
20 PRODUCED IO SIZE 0 16 5 — — Get
21 STATUS COS MASK 1 0 = Fault 0 — — Get/Set
1 = Warning 0
2 = IN1 Status 0
3 = IN2 Status 0
4 = IN3 Status 0
5 = IN4 Status 0
6 = IN5 Status 0
7 = Starting 0
8 = AUX1 Status 0
9 = AUX2 Status 0
10 = AUX3 Status 0
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
