Removing an option card – Rockwell Automation 825-P Modular Protection System for Motors User Manual User Manual
Page 50
50
Rockwell Automation Publication 825-UM004D-EN-P - November 2012
Chapter 4 Hardware Commissioning
Removing an Option Card
•
Remove control power from the relay, and remove the back cover
•
Remove the option card from the 825-P
•
Replace the cover and reapply control power to the relay
•
The display will show the following message to indicate that something is
different with the hardware configuration:
•
Navigate to Main > Status to view the Status display
•
The display will show the following message:
•
Press the Enter key to confirm that you want this hardware change
•
Select Yes to confirm the new hardware configuration, and the display
will show:
•
Press Enter to reboot the relay
STATUS FAIL
xxxxxx Card Fail
Confirm Hardware
Config (Enter)
Confirm Config?
Yes No
Config Accepted
Enter to Reboot
