Page 246: Byte, Bit 7, Bit 6, Bit 5, Bit 4, Bit 3, Bit 2
246
Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter E DeviceNet Information
Custom Parameter Based
Input (Produced) Assembly
Instance 100
1
187
Produced
Warn Status 1
188
Produced
Warn Status 2
189
Produced
Module Status Bits
Instance
Type
Description
Instance 100
Word
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
0
Value of the parameter pointed to by “Produced Word 0 Param” (low byte)
1
Value of the parameter pointed to by “Produced Word 0 Param” (high byte)
1
2
Value of the parameter pointed to by “Produced Word 1 Param” (low byte)
3
Value of the parameter pointed to by “Produced Word 1 Param” (high byte)
2
4
Value of the parameter pointed to by “Produced Word 2 Param” (low byte)
5
Value of the parameter pointed to by “Produced Word 2 Param” (high byte)
3
6
Value of the parameter pointed to by “Produced Word 3 Param” (low byte)
7
Value of the parameter pointed to by “Produced Word 3 Param” (high byte)
4
8
Value of the parameter pointed to by “Produced Word 4 Param” (low byte)
9
Value of the parameter pointed to by “Produced Word 4 Param” (high byte)
5
10
Value of the parameter pointed to by “Produced Word 5 Param” (low byte)
11
Value of the parameter pointed to by “Produced Word 5 Param” (high byte)
6
12
Value of the parameter pointed to by “Produced Word 6 Param” (low byte)
13
Value of the parameter pointed to by “Produced Word 6 Param” (high byte)
7
14
Value of the parameter pointed to by “Produced Word 7 Param” (low byte)
15
Value of the parameter pointed to by “Produced Word 7 Param” (high byte)
