208 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter B Parameter List
VAR
Settings
245 40146 400146 NEG VAR TRIP EN 0 = N 0 — — Get/Set
246 40147 400147 NEG VAR TRIP LEV 1 2500 2500 1 kVAR Get/Set
247 40148 400148 POS VAR TRIP EN 0 = N 0 — — Get/Set
1 = Y
248 40149 400149 POS VAR TRIP LEV 1 2500 2500 1 kVAR Get/Set
249 40150 400150 VAR TRIP DELAY 0 240 0 1 s Get/Set
250 40151 400151 NEG VAR WARN EN 0 = N 0 — — Get/Set
1 = Y
251 40152 400152 NEG VAR WARN LEV 1 2500 2500 1 kVAR Get/Set
252 40153 400153 POS VAR WARN EN 0 = N 0 — — Get/Set
1 = Y
253 40154 400154 POS VAR WARN LEV 1 2500 2500 1 kVAR Get/Set
254 40155 400155 VAR WARN DELAY 0 240 0 1 s Get/Set
Underpower
Set
255 40156 400156 UP TRIP ENABLE 0 = N 0 — — Get/Set
1 = Y
256 40157 400157 UP TRIP LEVEL 1 2500 2500 1 kW Get/Set
257 40158 400158 UP TRIP DELAY 0 240 0 1 s Get/Set
258 40159 400159 UP WARN ENABLE 0 = N 0 — — Get/Set
1 = Y
259 40160 400160 UP WARN LEVEL 1 2500 2500 1 kW Get/Set
260 40161 400161 UP WARN DELAY 0 240 0 1 s Get/Set
Power
Factor Set
261 40162 400162 PF LAG TRIP ENBL 0 = N 0 — — Get/Set
1 = Y
262 40163 400163 PF LAG TRIP LEVL 5 99 50 100 — Get/Set
263 40164 400164 PF LD TRIP ENABL 0 = N 0 — — Get/Set
1 = Y
264 40165 400165 PF LD TRIP LEVL 5 99 50 100 — Get/Set
265 40166 400166 PF TRIP DELAY 0 240 0 1 s Get/Set
266 40167 400167 PF LAG WARN ENBL 0 = N 0 — — Get/Set
267 40168 400168 PF LAG WARN LEVL 5 99 50 100 — Get/Set
268 40169 400169 PF LD WARN ENABL 0 = N 0 — — Get/Set
1 = Y
269 40170 400170 PF LD WARN LEVL 5 99 50 100 — Get/Set
270 40171 400171 PF WARN DELAY 0 240 0 1 s Get/Set
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
