Rockwell Automation Publication 825-UM004D-EN-P - April 2012

257

DeviceNet Information Chapter E

Parameter Object - CLASS
CODE 0x000F

The following class attributes are supported for the Parameter Object:

There is a standard set of instances reserved (1…100) for 825-PDN

DeviceNet Communication Card specific parameters. These instances are
followed by the motor relay parameters.

Refer to AppendixB of the 825-P Modular Protection System User Manual
(publication 825-UM004) for details of the individual motor relay parameter
instances.

The following services are implemented for the Parameter Object:

Attribute ID

Access Rule

Name

Data Type

Value

1

Get

Revision

UINT

2

Get

Max Instance

UINT

8

Get

Parameter Class Descriptor

WORD

9

Get

Configuration Assembly Instance

UINT

0

Service Code

Implemented for:

Service Name

Class

Instance

0x0E

Yes

Yes

Get_Attribute_Single

0x10

No

Yes

Set_Attribute_Single

0x01

No

Yes

Get_Attributes_All
