Rockwell Automation Publication 825-UM004D-EN-P - April 2012 207
Parameter List Chapter B
RTD
Settings
(cont.)
223 40124 400124 RTD11 TYPE 0 = Pt100
1 = Ni100
2 = Ni120
3 = Cu10
0 — — Get/Set
224 40125 400125 RTD11 TRIP LEVEL 0 = Off 250 0 1 °C Get/Set
225 40126 400126 RTD11 WARN LEVEL 0 = Off 250 0 1 °C Get/Set
226 40127 400127 RTD12 LOCATION 0 = Off
1 = Wdg
2 = Brg
3 = Amb
4 = Oth
0 — — Get/Set
227 40128 400128 RTD12 TYPE 0 = Pt100
1 = Ni100
2 = Ni120
3 = Cu10
0 — — Get/Set
228 40129 400129 RTD12 TRIP LEVEL 0 = Off 250 0 1 °C Get/Set
229 40130 400130 RTD12 WARN LEVEL 0 = Off 250 0 1 °C Get/Set
230 40131 400131 WIND TRIP VOTING 0 = N 0 — — Get/Set
1 = Y
231 40132 400132 BEAR TRIP VOTING 0 = N 0 — — Get/Set
1 = Y
232 40133 400133 TMP RTD BIASING 0 = N 0 — — Get/Set
1 = Y
Undervoltage
Set
233 40134 400134 UV TRIP ENABLE 0 = N 0 — — Get/Set
1 = Y
234 40135 400135 UV TRIP LEVEL 60 100 80 100 x Vnm Get/Set
235 40136 400136 UV TRIP DELAY 0 1200 0 10 s Get/Set
236 40137 400137 UV WARN ENABLE 0 = N 0 — — Get/Set
1 = Y
237 40138 400138 UV WARN LEVEL 60 100 80 100 x Vnm Get/Set
238 40139 400139 UV WARN DELAY 0 1200 0 10 s Get/Set
Overvoltage
Set
239 40140 400140 OV TRIP ENABLE 0 = N 0 — — Get/Set
1 = Y
240 40141 400141 OV TRIP LEVEL 100 120 110 100 x Vnm Get/Set
241 40142 400142 OV TRIP DELAY 0 1200 0 10 s Get/Set
242 40143 400143 OV WARN ENABLE 0 = N 0 — — Get/Set
1 = Y
243 40144 400144 OV WARN LEVEL 100 120 110 100 x Vnm Get/Set
244 40145 400145 OV WARN DELAY 0 1200 0 10 s Get/Set
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
