Parameter List Chapter B
Short Ckt
Set
130 40031 400031 SC TRIP ENABLE 0 = N 0 — — Get/Set
1 = Y
131 40032 400032 SC TRIP LEVEL 400 1200 1000 100 x Ie Get/Set
132 40033 400033 SC TRIP DELAY 0 500 0 100 s Get/Set
133 40034 400034 SC WARN ENABLE 0 = N 0 — — Get/Set
1 = Y
134 40035 400035 SC WARN LEVEL 400 1200 1000 100 x Ie Get/Set
135 40036 400036 SC WARN DELAY 0 500 50 100 s Get/Set
GF-CB
Settings
136 40037 400037 GF-CB TRIP EN 0 = N 0 — — Get/Set
1 = Y
137 40038 400038 GF-CB TRIP LEVEL 1 2500 100 100 A Get/Set
138 40039 400039 GF-CB TRIP DELAY 0 500 0 100 s Get/Set
139 40040 400040 GF-CB WARN EN 0 = N 0 — — Get/Set
1 = Y
140 40041 400041 GF-CB WARN LEVEL 1 2500 100 100 A Get/Set
141 40042 400042 GF-CB WARN DELAY 0 500 0 100 s Get/Set
GF-Res
Settings
142 40043 400043 GF-RES TRIP EN 0 = N 0 — — Get/Set
1 = Y
143 40044 400044 GF-RES TRIP LEVL 10 100 50 100 x Ie Get/Set
144 40045 400045 GF-RES TRIP DLAY 0 500 0 100 s Get/Set
145 40046 400046 GF-RES WARN EN 0 = N 0 — — Get/Set
1 = Y
146 40047 400047 GF-RES WARN LEVL 10 100 50 100 x Ie Get/Set
147 40048 400048 GF-RES WARN DLAY 0 500 0 100 s Get/Set
Jam
Settings
148 40049 400049 JAM TRIP ENABLE 0 = N 0 — — Get/Set
1 = Y
149 40050 400050 JAM TRIP LEVEL 100 600 200 100 x Ie Get/Set
150 40051 400051 JAM TRIP DELAY 0 1200 0 10 s Get/Set
151 40052 400052 JAM WARN ENABLE 0 = N 0 — — Get/Set
1 = Y
Undercurrent
Set
154 40055 400055 UC TRIP ENABLE 0 = N 0 — — Get/Set
155 40056 400056 UC TRIP LEVEL 10 100 50 100 x Ie Get/Set
156 40057 400057 UC TRIP DELAY 0 1200 50 10 s Get/Set
157 40058 400058 UC WARN ENABLE 0 = N 0 — — Get/Set
1 = Y
158 40059 400059 UC WARN LEVEL 10 100 50 100 x Ie Get/Set
159 40060 400060 UC WARN DELAY 0 1200 100 10 s Get/Set
160 40061 400061 UC START INHIBIT 0 1500 0 1 s Get/Set
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
