206 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter B Parameter List
RTD
Settings
(cont.)
207 40108 400108 RTD7 TYPE 0 = Pt100
1 = Ni100
2 = Ni120
3 = Cu10
0 — — Get/Set
208 40109 400109 RTD7 TRIP LEVEL 0 = Off 250 0 1 °C Get/Set
209 40110 400110 RTD7 WARN LEVEL 0 = Off 250 0 1 °C Get/Set
210 40111 400111 RTD8 LOCATION 0 = Off
1 = Wdg
2 = Brg
3 = Amb
4 = Oth
0 — — Get/Set
211 40112 400112 RTD8 TYPE 0 = Pt100
1 = Ni100
2 = Ni120
3 = Cu10
0 — — Get/Set
212 40113 400113 RTD8 TRIP LEVEL 0 = Off 250 0 1 °C Get/Set
213 40114 400114 RTD8 WARN LEVEL 0 = Off 250 0 1 °C Get/Set
214 40115 400115 RTD9 LOCATION 0 = Off
1 = Wdg
2 = Brg
3 = Amb
4 = Oth
0 — — Get/Set
215 40116 400116 RTD9 TYPE 0 = Pt100
1 = Ni100
2 = Ni120
3 = Cu10
0 — — Get/Set
216 40117 400117 RTD9 TRIP LEVEL 0 = Off 250 0 1 °C Get/Set
217 40118 400118 RTD9 WARN LEVEL 0 = Off 250 0 1 °C Get/Set
218 40119 400119 RTD10 LOCATION 0 = Off
1 = Wdg
2 = Brg
3 = Amb
4 = Oth
0 — — Get/Set
219 40120 400120 RTD10 TYPE 0 = Pt100
1 = Ni100
2 = Ni120
3 = Cu10
0 — — Get/Set
220 40121 400121 RTD10 TRIP LEVEL 0 = Off 250 0 1 °C Get/Set
221 40122 400122 RTD10 WARN LEVEL 0 = Off 250 0 1 °C Get/Set
222 40123 400123 RTD11 LOCATION 0 = Off
1 = Wdg
2 = Brg
3 = Amb
4 = Oth
0 — — Get/Set
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
