DeviceNet Information Chapter E
Five Instances of the Discrete Input Point Object are supported. All instances
contains the following attributes:
The following services are implemented for the Discrete Input Point Object:
Discreet Output Point
Object - CLASS CODE 0x0009
The following class attributes are supported for the Discrete Output Point
Object:
Six Instances of the Discrete Output Point Object are supported. All instances
contains the following attributes:
The following services are implemented for the Discrete Output Point Object:
Attribute ID Access Rule Name Data Type Value
3 Get Value BOOL 0 = OFF, 1 = ON
115 Get/Set Force Enable BOOL 0 = Disable, 1 = Enable
116 Get/Set Force Value BOOL 0 = OFF, 1 = ON
Service Code
Implemented for:
Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instance UINT 2, 6, or 10
Attribute ID Access Rule Name Data Type Value
3 Get Value BOOL 0 = OFF, 1 = ON
115 Get/Set Force Enable BOOL 0 = Disable, 1 = Enable
116 Get/Set Force Value BOOL 0 = OFF, 1 = ON
117 Get/Set Input Binding STRUCT:
USINT
Array of USINT
Size of appendix I encoded path
Appendix I encoded path
NULL path means attribute 3
drives the output.
Otherwise, this is a path to a bit
in the Bit Table.
