Rockwell Automation Publication 825-UM004D-EN-P - April 2012 197
Parameter List Chapter B
DeviceNet
(cont)
21 (cont.) STATUS COS MASK 1
(cont.)
11 = AUX4 Status 0 — — Get/Set
12 = AUX5 Status 0
13 = AUX6 Statusr 0
14 = Running 0
15 = Stopped 0
22 STATUS COS MASK 2 0 = Reserved 0 — — Get/Set
1 = Reserved 0
2 = IN6 Status 0
3 = IN7 Status 0
4 = IN8 Status 0
5 = IN4 Status 0
6 = IN5 Status 0
7 = Reserved 0
8 = AUX7 Status 0
9 = AUX8 Status 0
10 = AUX9 Status 0
11 = AUX10 Status 0
23 FAULT1 COS MASK 0 = Overload 0 — — Get/Set
1 = Undercurrent 0
2 = Jam 0
3 = Curr.Imballance 0
4 = Short Circuit 0
5 = RTD - Wind/Bear 0
6 = PTC 0
7 = GF - Residual 0
8 = VAR 0
9 = Underpower 0
10 = Undervoltage 0
11 = Overvoltage 0
12 = Phase Reversal 0
13 = Power Factor 0
14 = Speed Switch 0
15 = GF - Core Bal 0
24 FAULT2 COS MASK 0 = Start Time 0 — — Get
1 = Frequency 1 0
2 = Frequency 2 0
3 = RTD - Other 0
4 = RTD - Ambient 0
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
