230 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter B Parameter List
Historical
Data
419 40320 NO. EVENT LOGS 0 5 — 1 — Get
420 40321 400321 EVENT LOG SEL. 0 5 — 1 — Get/Set
421 40322 EVENT TIME ss 0 5999 — 1 — Get
422 40323 EVENT TIME mm 0 59 — 100 — Get
423 40324 EVENT TIME hh 0 23 — 1 — Get
424 40325 EVENT DAY dd 1 31 — 1 — Get
425 40326 EVENT DAY mm 1 12 — 1 — Get
426 40327 EVENT DAY yy 2000 9999 — 1 — Get
427 40328 EVENT TYPE 0=No Trip — — — Get
1=Overload Trip
2=Lockd Rotor Trip
3=Undercurr Trip
4=Jam Trip
5=Curr Imbal Trip
6=Short Ckt Trip
7=Ground Flt Trip
8=Speed Sw Trip
9=Undervolt Trip
10=Overvolt Trip
11=Underpower Trip
12=Pwr Factor Trip
13=React Pwr Trip
14=Phase Rev Trip
15=Underfreq Trip
16=Overfreq Trip
17=RTD Trip
18=PTC Trip
19=Start Time Trip
20=MCM/CWE Fail
21=RTD Fail Trip
22=PTC Fail Trip
23=Reserved
24=Trigger
25=CommIdleLossTrip
26=Remote Trip
27=Comm Fail Trip
28=TestButton Trip
428 40329 EVENT L1 0 65535 — 1 A Get
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
