Chapter 12 ASCII Serial Communications
Figure 57 - SHOW Command Example
STATUS (Level 1 or 2)
The STATUS command displays the relay hardware and software self-test
diagnostics and resolves hardware configuration conflicts when detected (see
Figure 58).
To view a status report, enter the STATUS command. To view the status report
k
times, enter the command STATUS
k, where k is a number between 1 and 32767.
Table 105 shows the status report definitions and message formats for each test.
=>SHO
RID :=825-P Modular
TID :=Prot. System
PHROT := ABC FNOM := 60 DATE_F := MDY CTR1 := 5
FLA1 := 25.0 E2SPEED := N CTRN := 100 PTR := 5.00
VNOM := 600 DELTA_Y := WYE
E49MOTOR:= Y 49RSTMD := AUTO 49RSTP := 75 SF := 1.00
LRA1 := 12.0 LRTHOT1 := 10.0 TD1 := 1.00 RTC1 := AUTO
TCAPU := 85 TCSTART := OFF COOLTIME:= 44 ETHMBIAS:= Y
50P1P := OFF 50P2P := OFF 50N1P := OFF 50N2P := OFF
50G1P := OFF 50G2P := OFF
LJTPU := OFF LJAPU := OFF
LLTPU := OFF LLAPU := OFF
46UBT := OFF 46UBA := 10 46UBAD := 10 PROTBL_T:= OFF
THERBL_T:= OFF
START_T := OFF
ESTAR_D := N
MAXSTART:= OFF TBSDLY := OFF
ABSDLY := OFF
E47T := N
SPDSDLYT:= OFF SPDSDLYA:= OFF
EPTC := N
E49RTD := Y RTDRST := AUTO RTD1LOC := WDG RTD1TY := PT100
TRTMP1 := 150 ALTMP1 := 120 RTD2LOC := OFF RTD3LOC := WDG
RTD3TY := PT100 TRTMP3 := OFF ALTMP3 := OFF RTD4LOC := WDG
RTD4TY := PT100 TRTMP4 := OFF ALTMP4 := OFF RTD5LOC := WDG
RTD5TY := PT100 TRTMP5 := OFF ALTMP5 := OFF RTD6LOC := WDG
RTD6TY := PT100 TRTMP6 := OFF ALTMP6 := OFF RTD7LOC := BRG
RTD7TY := PT100 TRTMP7 := OFF ALTMP7 := OFF RTD8LOC := BRG
RTD8TY := PT100 TRTMP8 := OFF ALTMP8 := OFF RTD9LOC := BRG
RTD9TY := PT100 TRTMP9 := OFF ALTMP9 := OFF RTD10LOC:= BRG
RTD10TY := PT100 TRTMP10 := OFF ALTMP10 := OFF RTD11LOC:= AMB
RTD11TY := PT100 TRTMP11 := OFF ALTMP11 := OFF RTD12LOC:= OTH
RTD12TY := PT100 TRTMP12 := OFF ALTMP12 := OFF EWDGV := N
EBRGV := N ERTDBIAS:= N
27P1P := OFF 27P2P := OFF
59P1P := OFF 59P2P := OFF
NVARTP := OFF PVARTP := OFF NVARAP := OFF PVARAP := OFF
37PTP := OFF 37PAP := OFF
55LGTP := 0.50 55LDTP := OFF 55TD := 1 55LGAP := 0.50
55LDAP := OFF 55AD := 1
81D1TP := OFF 81D1AP := OFF
81D2TP := OFF
81D2AP := OFF
LOAD := OFF
AOPARM := LOAD_I
BLK46 := N BLK48 := N BLK50EF := N BLK50P := N
BLK37 := N BLK66 := N BLK49PTC:= N BLK49RTD:= N
TRIPFS := Y AUX1FS := Y AUX2FS := Y AUX3FS := Y
AUX4FS := Y AUX5FS := Y AUX6FS := Y
T1ONDLY := 0 T1OFFDLY:= 0 T2ONDLY := 0 T2OFFDLY:= 0
FP_TO := 15 FP_CONT := 5
FP_TD := N FP_GC := N FP_LA := N FP_MF := N
FP_TH := N FP_VA := N FP_PE := N FP_RTD := N
=>
