Rockwell Automation Publication 825-UM004D-EN-P - April 2012 225
Parameter List Chapter B
I/O
Mapping
(cont.)
330 40231 400231 IN3 ASSIGN 0=Emergency Start 0 — — Get/Set
1=Disable Settings 0
2=Trip Reset 0
3=Timer 1 0
4=Timer 2 0
5=Speed Switch 0
6=Block Protection 0
7=Speed 2 0
8=Bkr/Cont Aux 0
9=Remote Trip 0
10=Reserved 0
11=Reserved 0
12=Reserved 0
13=Reserved 0
14=Reserved 0
15=Reserved 0
331 40232 400232 IN4 ASSIGN 0=Emergency Start 0 — — Get/Set
1=Disable Settings 0
2=Trip Reset 0
3=Timer 1 0
4=Timer 2 0
5=Speed Switch 0
6=Block Protection 0
7=Speed 2 0
8=Bkr/Cont Aux 0
9=Remote Trip 0
10=Reserved 0
11=Reserved 0
12=Reserved 0
13=Reserved 0
14=Reserved 0
15=Reserved 0
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
