Rockwell Automation Publication 825-UM004D-EN-P - April 2012 209
Parameter List Chapter B
Freq
Settings
271 40172 400172 FREQ1 TRIP ENABL 0 = N 0 — — Get/Set
1 = Y
272 40173 400173 FREQ1 TRIP LEVEL 450 650 600 10 Hz Get/Set
273 40174 400174 FREQ1 TRIP DELAY 0 2400 10 10 s Get/Set
274 40175 400175 FREQ1 WARN ENABL 0 = N 0 — — Get/Set
1 = Y
275 40176 400176 FREQ1 WARN LEVEL 450 650 600 10 Hz Get/Set
276 40177 400177 FREQ1 WARN DELAY 0 2400 10 10 s Get/Set
277 40178 400178 FREQ2 TRIP ENABL 0 = N 0 — — Get/Set
1 = Y
278 40179 400179 FREQ2 TRIP LEVEL 450 650 600 10 Hz Get/Set
279 40180 400180 FREQ2 TRIP DELAY 0 2400 10 10 s Get/Set
280 40181 400181 FREQ2 WARN ENABL 0 = N 0 — — Get/Set
1 = Y
281 40182 400182 FREQ2 WARN LEVEL 450 650 600 10 Hz Get/Set
282 40183 400183 FREQ2 WARN DELAY 0 2400 10 10 s Get/Set
Load
Control Set
283 40184 400184 LOAD CONTROL SEL 0 = Off 0 — — Get/Set
1 = Current
2 = Power
3 = TCU
284 40185 400185 LD CTL UPP ENABL 0 = N 0 — — Get/Set
1 = Y
285 40186 400186 LD CTL CUR UPPER 20 200 50 10 x Ie Get/Set
286 40187 400187 LD CTL PWR UPPER 1 25000 22500 1 kW Get/Set
287 40188 400188 LD CTL TCU UPPER 1 99 90 1 %TCU Get/Set
288 40189 400189 LD CTL LOW ENABL 0 = N 0 — — Get/Set
1 = Y
289 40190 400190 LD CTL CUR LOWER 20 200 50 10 x Ie Get/Set
290 40191 400191 LD CTL PWR LOWER 1 25000 12500 1 kW Get/Set
291 40192 400192 LD CTL TCU LOWER 1 99 90 1 %TCU Get/Set
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
