202 Rockwell Automation Publication 825-UM004D-EN-P - April 2012
Chapter B Parameter List
Main
Settings
101 40002 400002 PHASE ROTATION 0 = ABC 0 — — Get/Set
1 = ACB
102 40003 400003 RATED FREQ. 0 = 50 1 — Hz Get/Set
1 = 60
103 40004 400004 DATE FORMAT 0 = MDY 0 — — Get/Set
1 = YMD
2 = DMY
104 40005 400005 PHASE CT RATIO 1 5000 1 1 — Get/Set
105 40006 400006 MOTOR FLA(Ie) 5 50000 5 10 A Get/Set
106 40007 400007 TWO SPEED ENABLE 0 = N 0 — — Get/Set
1 = Y
107 40008 400008 CT RATIO-2nd 1 5000 1 1 — Get/Set
108 40009 400009 MOTOR FLA-2nd 5 50000 5 10 A Get/Set
109 40010 400010 CORE B. CT RATIO 1 2000 100 1 — Get/Set
110 40011 400011 PHASE VT RATIO 100 25000 1 100 — Get/Set
111 40012 400012 LINE VOLTAGE 100 30000 100 1 — Get/Set
112 40013 400013 XFMR CONNECTION 0 = Delta 0 — — Get/Set
1 = Wye
Overload
Set
113 40014 400014 OVERLOAD ENABLE 0 = N 1 — — Get/Set
1 = Y
114 40015 400015 OL RESET MODE 0 = Manual 0 — — Get/Set
1 = Auto
115 40016 400016 OL RESET LEVEL 10 99 75 1 %TCU Get/Set
116 40017 400017 SERVICE FACTOR 101 150 101 100 — Get/Set
117 40018 400018 MOTOR LRC 25 120 60 10 x Ie Get/Set
118 40019 400019 LOCKD ROTOR TIME 10 6000 100 10 s Get/Set
119 40020 400020 ACCEL FACTOR 10 150 100 100 — Get/Set
120 40021 400021 RUN STATE TIME K 0 = Auto 2000 0 1 min Get/Set
121 40022 400022 MOTOR LRC - 2nd 25 120 60 10 x Ie Get/Set
122 40023 400023 MOTOR LRT - 2nd 10 6000 100 10 s Get/Set
123 40024 400024 ACCEL FACT - 2nd 10 150 100 100 — Get/Set
124 40025 400025 RUN ST TC - 2nd 0 = Auto 2000 0 1 min Get/Set
125 40026 400026 OL WARN ENABLE 0 = N 1 — — Get/Set
1 = Y
126 40027 400027 OL WARN LEVEL 50 99 85 1 %TCU Get/Set
127 40028 400028 START INH. LEVEL 0 = Off 99 0 1 %TCU Get/Set
128 40029 400029 STOP COOL TIME 1 2200 18 1 min Get/Set
129 40030 400030 OL RTD BIASING 0 = N 0 — — Get/Set
1 = Y
Group
DeviceNet
Param No.
Modbus Register
Parameter Name Min Max Default
Scale
Factor
Units Access
Read (0x03h) Write (0x06h)
