Appendix
D
ASCII Port Relay Command Summary
ASCII Port Relay The ASCII Port Relay Command Summary table below lists the front serial port
ASCII commands associated with particular activities. The commands are shown
in upper-case letters, but they can also be entered with lower-case letters.
Serial Port Command Access Level Command Description
2AC 1, 2 Go to Access Level 2.
ACC 0, 2 Go to Access Level 1.
ANA 2 Test analog output (refer to Chapter 12: ASCII Serial Communications for details).
DAT 1, 2 View date.
DAT mm/dd/yyyy 1, 2 Enter date in MDY format if DATE_F setting is MDY.
DAT dd/mm/yyyy 1, 2 Enter date in DMY format if DATE-F setting is DMY.
DAT yyyy/mm/dd 1, 2 Enter date in YMD format if DATE-F setting is YMD.
MET 1, 2 Display instantaneous metering data.
MET k 1, 2 Display instantaneous metering data k times, where k is 1…32767.
MET T 1, 2 Display thermal and RTD metering data.
MOT 1, 2 Display motor operating statistics report.
MOT R or C 2 Reset motor operating statistics.
PAS 2 Show existing Access Level 1 and Level 2 passwords.
PAS 1 xxxxxxxx 2 Change Access Level 1 password to xxxxxxxx
PAS 2 xxxxxxxx 2 Change Access Level 2 password to xxxxxxxx
QUI 1, 2 Go to Access Level 0.
SER 1, 2 Display all Sequential Events Recorder (SER) data.
SER n 1, 2 Display the n most recent SER records starting with record n.
SER n1 n2 1, 2 Display SER records n2…n1, starting with n2.
SER d1 1, 2 Display all SER records made on date d1.
SER d1 d2 1, 2 Display all SER records made from dates d2…d1, inclusive, starting with d2.
SER R or C 1, 2 Reset SER data.
SET 2 Enter/change relay settings.
SET P 2 Enter/change Serial Port F settings.
SET M 2 Enter/change I/O mapping settings.
SET name 2 For all SET commands, jump ahead to a specific setting by entering setting name, e.g., 50P1P.
SET …TERSE 2 For all SET commands, TERSE disables the automatic SHO command after settings entry.
SHO 1, 2 Show relay settings.
SHO A 1, 2 Show all relay settings: enabled and disabled/hidden.
