16 Rockwell Automation Publication 825-UM004D-EN-P - November 2012
Chapter 1 Introduction
Figure 1 - AC Connections Without CTs
825-P 825-MCM
L3 L2 L1
A1
1 3 5
6 4 2
A2
M
3 ~
Converter Module
Cat. No. 825-MCM2
Cat. No. 825-MCM5
Cat. No. 825-MCM20
Cat. No. 825-MCM180
Cat. No. 825-MCM420
Cat. No. 825-MCM630N
