Troubleshooting and fault elimination
System error messages
General error messages
9
9.3
9.3.1
l
9.3−5 EDSVS9332P EN 5.0−07/2013
Remedy Cause Description Fault message Remedy Cause Description
Display No.
x088 Sd8 SinCos encoder at X8 sends
inconsistent data. The tracks in the SinCos encoder
are damaged. Replace SinCos encoder.
Interference level on the encoder
cable is too high. l Check correct shield
connection of encoder cable.
l Where required, decelerate the
actuation of the fault message
via the filter time constant.
Setting:
– for ECSxS/P/M/A in C0559.
– for 9300 servo cam in
C0575.
SinCos encoder at X8 does not
send any data. Open circuit. Check cable for wire breakage.
Incorrect encoder connected. Connect SinCos encoder of the
Stegmann company.
SinCos encoder is defective. Replace SinCos encoder.
Supply voltage set incorrectly. Set voltage supply in C0421.
After fault correction: completely
deenergise the device (switch off
24 V supply, discharge DC bus)!
x089 PL Error during rotor position
adjustment (the error is saved
with mains failure protection) l The rotor position adjustment
was cancelled.
l During rotor position
adjustment with an absolute
value encoder the error Sd7 or
SD8 occurred.
Repeat rotor position adjustment.
^ 6.8−1
Note: After an Sd7 fault it is
absolutely required to carry out
another rotor position
adjustment. Otherwise the drive
may carry out uncontrolled
movements after controller
enable. The drive must not be
commissioned without a
successfully executed rotor
position adjustment!
x091 EEr External monitoring has been
triggered via DCTRL. A digital signal assigned to the
TRIP−SET function has been
activated. l Check external encoder.
l Switch off the monitoring
(C0581 = 3).
0105 H05 Internal fault (memory) Contact Lenze.
0107 H07 Internal fault (power stage) During initialisation of the
controller, an incorrect power
stage was detected. Contact Lenze.
x110 H10 Heatsink temperature sensor
error Sensor for detecting the heatsink
temperature indicates undefined
values. l Contact Lenze.
l Switch off the monitoring
(C0588 = 3).
x111 H11 Temperature sensor error:
Temperature inside the controller Sensor for detecting the internal
temperature indicates undefined
values. l Contact Lenze.
l Switch off the monitoring
(C0588 = 3).
x151 P01 Error "negative limit switch". Negative limit switch was
reached. l Control drive in positive
direction
l Check wiring at X5/E2.
x152 P02 Error "positive limit switch". Positive limit switch was reached. l Control drive in negative
direction
l Check wiring at X5/E1.
x153 P03 Following error The angle difference between set
and actual position is larger than
the following error limit set under
C0255. l Increase following error limit
under C0255.
l Switch off the monitoring
(C0589 = 3).
Drive cannot follow the digital
frequency (I
max
limit).
Check drive dimensioning.
