Configuration
Basic configurations
8
8.5
l
8.5−55 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C1213 REF. MODE 0 Homing mode
l Mode for homing (valid for
manual mode and program
homing).
^ 6.13−1
See system
manual
(extension)
Travel direction
0 +home positive Move to reference point via
homing switch
1 −home negative
2 +LIM,−home positive Approach end of travel range
limit switch, reverse and move
to reference point via homing
switch
3 −LIM,+home negative
4 +MARK,−home positive Move to homing switch, reverse
and move to reference point
5 −MARK,+home negative
6 +MARK,+TP positive Move to TP signal via reference
switch
7 −MARK,−TP negative
8 +TP positive Directly travel to TP signal
9 −TP negative
10 +LIM,−TP positive Move to the travel range limit
switch, reverse there, and
reference to TP
11 −LIM,+TP negative
C1214 REF TP−INPUT 4 1
2
3
4 TP−IN = X5/E1
TP−IN = X5/E2
TP−IN = X5/E3
TP−IN = X5/E4 Homing touch probe
l Selection of the touch probe
input (TP−IN) for homing acc.
to modes 6...9. When using
an incremental encoder, the
TP input X5/E4 is particularly
suitable.
See system
manual
(extension)
C1215 0
1 LOW/HIGH edge
HIGH/LOW edge TP input edge
l Selection of the edge for the
touch probe input terminals.
(Applies to homing acc. to
modes 6...9, TP positioning,
TP storage)
See system
manual
(extension)
1 TP−TRANS 0
2 TP−TRANS 0
3 TP−TRANS 0
4 TP−TRANS 0
C1216 V−REF2 ACTIVE. 0 0
1 inactive
active Homing speed
Activation of 2nd speed See system
manual
(extension)
C1218 0 {0.0001 units} 214000.
0000
POS
Following error tolerance See system
manual
(extension)
1 FOL.TOLERANC
E
4,0000
2 FOL.TOLERANC
E
1.0000
