Configuration
Basic configurations
8.5
l
8.5−58
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1260 MANUAL
MODE
0
0
1
Without intermediate stop
With intermediate stop
POS
Manual jog mode
See system
manual
(extension)
C1261
0
1
2
3
...
104
Inactive
VTPOS−No 001
VTPOS−No 002
VTPOS−No 003
...
VTPOS−No 104
POS
Intermediate stop target,
number in VTPOS
1 MANU−STP−NO
0
2 MANU−STP−NO
1
... ...
...
15 MANU−STP−NO
14
16 MANU−STP−NO
15
C1280 POS. CONTROL
0
0
{1}
65535 POS
Control word positioning
See system
manual
(extension)
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bits
8−15
Program start
Program stop
Program reset
Program abort
Manual operation
Negative manual jog
Positive manual jog
Manual homing
reserved
C1283 POS. STATUS
g
0
5
10
11
12
15
20
25
26
30
35
36
50
51
55
56
57
58
59
62
63
80
85
Program operation
Ready to start
Started
Started−dig
Started−rem
Started−break
Program end
Stopped−dig
Stopped−rem
Stand−by−operation
Program reset−dig
Program reset−rem
Manual operation−dig
Manual operation−rem
Manual−negative−dig
Manual−negative−rem
Manual−positive−dig
Manual−positive−rem
Manual negative and positive active
Manual referencing−dig
Manual referencing−rem
POS−LOOP−INH active
POS−PSET−SWT active
POS
Position status display
The state is only updated under
the following conditions:
l
Power section supplied:
DCTRL−RDY = 1
l
No fault:
DCTRL−TRIP = 0
DCTRL−FAIL−QSP = 0
l
Drive enabled:
DCTRL−CINH = 0
l
No quick stop (QSP) active:
MCTRL−QSP−OUT = 0
l
No manual operation active:
POS−MANUAL = 0
C1280.B4 = 0
See system
manual
(extension)
C1284 HOMING−
STATUS
g
0
1
5
10
11
20
25
No reference
Reference known
Prg−fct. homing active
Manual referencing−dig
Manual referencing − C1280
Absolute value encoder
External absolute value
POS
Homing status
See system
manual
(extension)
C1285
0
4
TRIP
Fail−QSP
Monitoring P01, P02, P04, P05
^ 8.31
1 MONIT P01
4
Negative limit switch
2 MONIT P02
4
Positive limit switch
3 MONIT P04
4
Limit position negative
4 MONIT P05
4
Limit position positive
