Configuration
Basic configurations
8
8.5
l
8.5−36 EDSVS9332P EN 5.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0798
g
−199.99 {0.01 %} 199.99 NSET
Display of analog input signals
See system
manual
(extension)
1 NSET−CINH−VA
L
2 NSET−SET
C0799
g NSET
Display of digital input signals
1 NSET−N−INV
2 NSET−NADD−IN
V
3 NSET−LOAD
4 NSET−JOG*1
5 NSET−JOG*2
6 NSET−JOG*4
7 NSET−JOG*8
8 NSET−TI*1
9 NSET−TI*2
10 NSET−TI*4
11 NSET−TI*8
12 NSET−RFG−0
13 NSET−RFG−STO
P
C0800
s
PCTRL1−SET 1000 FIXED0% ® Selection list 1 PCTRL1
Configuration of setpoint input
signal
See system
manual
(extension)
C0801
s
PCTRL1−ACT 1000 FIXED0% ® Selection list 1 PCTRL1
Configuration of actual value
input signal
C0802
s
PCTRL1−INFLU 1000 FIXED0% ® Selection list 1 PCTRL1
Configuration of evaluation
input signal
C0803
s
PCTRL1−ADAPT 1000 FIXED0% ® Selection list 1 PCTRL1
Configuration of adaptation
input signal
C0804
s
PCTRL1−INACT 1000 FIXED0 ® selection list 2 PCTRL1
Configuration of inactivation
input signal
C0805
s
PCTRL1−I−OFF 1000 FIXED0 ® selection list 2 PCTRL1
Configuration of digital input
signal (switch−off I component)
See system
manual
(extension)
C0808 g −199.99 {0.01 %} 199.99 PCTRL1
Display of analog input signals
1 PCTRL1−SET
2 PCTRL1−ACT
3 PCTRL1−INFLU
4 PCTRL1−ADAPT
C0809 g PCTRL1
Display of digital input signals
1 PCTRL1−INACT
2 PCTRL1−I−OFF
