Configuration
Basic configurations
8.5
l
8.5−81
EDSVS9332P EN 5.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1700
g
−2147483647
{1}
2147483647 BCD1
See system
manual
(extension)
1 OUTPUT
SIGNAL
Display of output signal
2 BCD RESULT
Display of the output signal
after the evaluation with
C1703/C1704 and C1705
C1701 BCD1 CODE
141
11
{1}
2000 BCD1
Code
C1702 BCD1
SUBCODE
0
0
{1}
255 BCD1
Subcode
C1703 BCD1
NUMERATOR
1
0
{1}
100000 BCD1
Numerator
C1704 BCD1
DENOMINATO
R
0.0001 0.0001
{0.0001}
100000.0000 BCD1
Denominator
C1705 BCD1 OFFSET
0
0
{1}
1000000000 BCD1
Offset
C1706 BCD MODE
0
0
1
Without acceptance signal
With acceptance signal
BCD1
Mode
C1707 BCD DELAY
10
0
{1 ms}
255 BCD1
Deceleration
C1708
s
® selection list 2 BCD1
Configuration of digital input
signals
See system
manual
(extension)
1 BCD1−READ
1000
FIXED0
2 BCD1−DATA1
1000
FIXED0
3 BCD1−DATA2
1000
FIXED0
4 BCD1−DATA3
1000
FIXED0
5 BCD1−DATA4
1000
FIXED0
6 BCD1−LOAD
1000
FIXED0
7 BCD1−BUSY−IN
1000
FIXED0
8 BCD1−FAIL−IN
1000
FIXED0
C1709
g
0
1 BCD1
Display of digital input signals
1 BCD1−READ
2 BCD1−DATA1
3 BCD1−DATA2
4 BCD1−DATA3
5 BCD1−DATA4
6 BCD1−LOAD
7 BCD1−BUSY−IN
8 BCD1−FAIL−IN
